Technical specifications:
The biggest printing area: 250 * 170 mm
The fastest speed: 5000 PCS/hn
Minimum vessel diameter: Φ 10 mm
The minimum height of container: 20 mm
The largest container diameter: 80 mm Φ
The largest container height: 200 mm
The UV lamp power: 2.4 kw each
Power requirements: 380 v
Air pressure requirements: 5 to 7 bar
Total power: 8 kw
The machine size: 2600 * 1500 * 2100 mm
Gas consumption: 100 l/min
Weight: 120 kg
Equipment performance:
U for cylindrical printing products and development, applicable to the hose, bottle caps, cosmetics pot products such as printing.
U have automatic feeding, electrostatic dust removal, flame treatment, servo positioning.
Taken the advanced and reliable high-speed screen printing with UV curing system, high quality printing packing.
U can be made according to request of product automatic feeding pipe system, a greater degree of lower labor costs and provide operational efficiency.
Taken the servo touch screen operation, realize the man-machine dialogue, and has perfect fault alarm system.
U for cosmetics hoses counterpoint printing and printing for many times, can be equipped with: 1, cursor registration system 2. Hose ripped cover fiber registration system.
